Samsung 46" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV
Smart TV 2.0 With Advanced Management. Premium in Every Way.

Samsung 46" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV

This product is no longer available, please contact us for a replacement.

Overview:

Samsung's 890 Series Hospitality TVs deliver superior picture and dynamic interactivity for a premium in-room experience with an at-home feel. With Smart TV 2.0, guests can stream movies and TV shows, check Facebook, Twitter and Skype to stay connected, and even push content from their mobile devices to the big screen. The hotelier can enjoy energy-saving performance and remote content management.

  • Premium Edge-Lit Ultra-Thin LED Technology
  • SMART TV 2.0
  • Samsung LYNK™ SINC 3.0 Interactive Content Management System
  • Samsung LYNK REACH 3.0 Content Management Solution

Features

Premium Edge-Lit Ultra-Thin LED

Edge-lit LED technology provides the brilliance and energy savings advantages of LED technology, along with the uniform brightness typical of CCFL displays. And it's possible to upgrade your rooms to LED technology for a cost comparable to CCFL technology.

SMART TV 2.0

Experience the next generation of our ground-breaking TVs with Smart Interaction, full web browsers, all-new content, all-new content services, faster processors and much more.

Samsung LYNK SINC 3.0

This IP-based content management system communicates between our TVs and hotel property management software. Customize entertainment with EPG (Electronic Program Guide), Weather API, Flight Info, Real Time Messaging and our Hospitality Widget Library (Facebook, Twitter, AccuWeather, Google Maps™).

Samsung LYNK REACH 3.0

The Samsung LYNK REACH 3.0 (Remote Enhanced Active Control for Hotels) content management solution is used in conjunction with an existing coaxial-based infrastructure. It provides centralized TV controls, basic static content management capabilities and an Interactive Program Guide (IPG).

H-Browser Compatibility

Built on the HTML5 standard with Flash® support, H-Browser is a true SMART TV solution offered on our 890 Series through partnerships with certified system integrators. It features both free and video on demand (VOD) content, and is able to interface directly with the head end without a set top box.

Samsung AllShare® Cast

Seamlessly share content across your DLNA connected Samsung devices including WIDI without the need for a network cable or a connecting device. AllShare Cast allows screen mirroring and video streaming to enable seamless content sharing and mobile device integration.

Specifications:


Samsung 46" 890 Series Edge-Lit Ultra-Thin LED Hospitality TV Specifications
Display
Backlight LED - Edge Lit
Screen Size (Diagonal) 46"
HD/FHD FHD
Resolution 1920 x 1080
Video
Picture Engine 3D HyperReal Engine
Micro Dimming Micro Dimming Pro
Wide Color Enhancer Plus Yes
Auto Motion Plus 240Hz
Film Mode Yes
Audio
Dolby Dolby MS10
DTS Studio Sound / DNSe+ DTS Studio Sound
DTS Premium Sound / DTS Premium Sound 5.1 DTS Premium Sound 5.1
3D Sound Yes
Auto Volume Leveler Yes
Speaker Type Down Firing + New Waveguide
Sound Output (RMS) 40W (Left:10W, Right:10W, Woofer:20W)
Woofer Yes
Variable Speaker Output 4W (Mono, 8)
Features
Smart Hub Yes
Apps Yes
Web Browser Yes
Samsung SMART View Yes
Voice Control Yes
Samsung 3D Yes
3D Converter Yes
Wireless LAN Built-in Yes
AllShare - Contents Sharing Yes
AllShare - Screen Mirroring Yes
ConnectShare™ (USB 2.0) Movie
Wake On LAN Yes
Soft AP Yes
BT HID Built-in Yes
USB HID Support Yes
TV SoundConnect Yes
OSD Language English, Spanish, French
Digital Clean View Yes
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A / Return Ch. Support (ARC) Yes
Anynet+ (HDMI-CEC) Yes
BD Wise Plus Yes
Auto Channel Search Yes
Auto Power Off Yes
EPG Yes
Caption (Subtitle) Yes
Wake-up Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Hospitality Features
Hospitality Home Menu Yes
Samsung LYNK™ REACH Server Compatibility Yes
Samsung LYNK™ SINC Compatibility Yes
H.Browser Compatibility Yes
Hospitality Plug&Play (Easy Set-up) Yes
RJ 12 / IR Pass Through Yes
Power on Mode Yes
USB Cloning Yes
Logo Display with Time Out Setting (BMP/Movie) Yes
Welcome Message Yes
Music Mode (Input: PC/AV/Component/HDMI) Yes
Music Mode BackLight on/off Yes
Auto Source Mode Yes
Energy Saving Mode (BLU control) Yes
Clock Back Up Supply Yes
Software Clock Yes
Multi Code Remote Control Yes
Screwed Remote Battery Cover Yes
Smoovie Compatibility Yes
Sound bar compatibility Yes
Samsung LYNK™ DRM Yes
Pro:Idiom Yes
Input & Output
HDMI (Side/Rear) 2/2
USB (Side/Rear) 1/0
Component In (Y/Pb/Pr) (Side/Rear) 0/1
Composite In (AV) (Side/Rear) 0/1 (1 Common Use for Component Y)
Ethernet (LAN) (Side/Rear) 1/0
Digital Audio Out (Optical) (Side/Rear) 0/1
Audio Out (Mini Jack) (Side/Rear) 0/1
PC/DVI Audio In (Mini Jack) (Side/Rear) 0/1
RF In (Terrestrial/Cable input) (Side/Rear) 1/0
RS232C (Common Use for RJ12)
Variable Audio Out (Side/Rear) 0/1
Variable Audio Out Volume Control (Side/Rear) 0/1
RJ12 for External Control (Side/Rear) 0/1
RJP Jack (Remote Jack Pack) (Side/Rear) 0/1
System
DTV Tuner ATSC / Clear QAM
Analog Tuner Yes
Design
Front Color Black
Stand Type U Stand
Dimension (WxHxD)
Set Dimension with Stand (WxHxD) (mm / Inch) 1033.3 x 639.20 x 208.8 / 40.68" x 25.17" x 8.22"
Set Dimension without Stand (WxHxD) (mm / Inch) 1033.3 x 596.9 x 33.2 / 40.48" x 23.5" x 1.3"
Carton Dimensions
Package Dimension (WxHxD) (mm / Inch) 1110 x 668 x 140 / 43.7" x 26.3" x 1.72"
Weight
Set Weight with Stand (kg / lbs) 12.5 / 27.6 lbs.
Set Weight without Stand (kg / lbs) 11.3 / 24.9 lbs.
Packaging Weight
Gross weight (kg / lbs) 15 / 33.1 lbs.
VESA Mounting
Dimensions (mm) 400 x 400
Screw Size M8
Power
Power Supply AC110-120V 60Hz
Multi Voltage AC110-220V
UPC
UPC 887276684420
Eco
Eco Mark TM1480 + TM1240
Eco Sensor Yes
Accessory
Package Dimension (WxHxD) (mm) Yes
Battery (for Remote Control) Yes
Vesa Wall Mount Support Yes
Slim Gender Cable Yes
Power Cable Yes

Compare:


Samsung 890 Series Hospitality TVs Comparison
Model Number HG46NC890XF HG55NC890XF HG65NC890XF HG75NC890XF
Display
Backlight LED - Edge Lit LED - Edge Lit LED - Edge Lit LED
Screen Size (Diagonal) 46" 55" 65" 75"
HD/FHD FHD FHD FHD FHD
Resolution 1920 x 1080 1920 x 1080 1920 x 1080 1920 x 1080
Video
Picture Engine 3D HyperReal Engine 3D HyperReal Engine 3D HyperReal Engine 3D HyperReal Engine
Micro Dimming Micro Dimming Pro Micro Dimming Pro Micro Dimming Pro Micro Dimming Pro
Wide Color Enhancer Plus Yes Yes Yes Yes
Auto Motion Plus 240Hz 240Hz 240Hz 240Hz
Film Mode Yes Yes Yes Yes
Audio
Dolby Dolby MS10 Dolby MS10 Dolby MS10 Dolby MS10
DTS Studio Sound / DNSe+ DTS Studio Sound DTS Studio Sound DTS Studio Sound DTS Studio Sound
DTS Premium Sound / DTS Premium Sound 5.1 DTS Premium Sound 5.1 DTS Premium Sound 5.1 DTS Premium Sound 5.1 DTS Premium Sound 5.1
3D Sound Yes Yes Yes Yes
Auto Volume Leveler Yes Yes Yes Yes
Speaker Type Down Firing + New Waveguide Down Firing + New Waveguide Down Firing + New Waveguide Down Firing + New Waveguide
Sound Output (RMS) 40W (Left:10W, Right:10W, Woofer:20W) 40W (Left:10W, Right:10W, Woofer:20W) 40W (Left:10W, Right:10W, Woofer:20W) 40W (Left:10W, Right:10W, Woofer:20W)
Woofer Yes Yes Yes Yes
Variable Speaker Output 4W (Mono, 8) 4W (Mono, 8) 4W (Mono, 8) 4W (Mono, 8Ω)
Features
Smart Hub Yes Yes Yes Yes
Apps Yes Yes Yes Yes
Web Browser Yes Yes Yes Yes
Samsung SMART View Yes Yes Yes Yes
Voice Control Yes Yes Yes Yes
Samsung 3D Yes Yes Yes Yes
3D Converter Yes Yes Yes Yes
Wireless LAN Built-in Yes Yes Yes Yes
AllShare - Contents Sharing Yes Yes Yes Yes
AllShare - Screen Mirroring Yes Yes Yes Yes
ConnectShare™ (USB 2.0) Movie Movie Movie Movie
Wake On LAN Yes Yes Yes Yes
Soft AP Yes Yes Yes Yes
BT HID Built-in Yes Yes Yes Yes
USB HID Support Yes Yes Yes Yes
TV SoundConnect Yes Yes Yes Yes
OSD Language English, Spanish, French English, Spanish, French English, Spanish, French English, Spanish, French
Digital Clean View Yes Yes Yes Yes
HDMI 1.4 3D Auto Setting Yes Yes Yes Yes
HDMI 1.4 A / Return Ch. Support (ARC) Yes Yes Yes Yes
Anynet+ (HDMI-CEC) Yes Yes Yes Yes
BD Wise Plus Yes Yes Yes Yes
Auto Channel Search Yes Yes Yes Yes
Auto Power Off Yes Yes Yes Yes
EPG Yes Yes Yes Yes
Caption (Subtitle) Yes Yes Yes Yes
Wake-up Timer Yes Yes Yes Yes
Game Mode Yes Yes Yes Yes
Picture-In-Picture Yes Yes Yes Yes
Sleep Timer Yes Yes Yes Yes
Hospitality Features
Hospitality Home Menu Yes Yes Yes Yes
Samsung LYNK™ REACH Server Compatibility Yes Yes Yes Yes
Samsung LYNK™ SINC Compatibility Yes Yes Yes Yes
H.Browser Compatibility Yes Yes Yes Yes
Hospitality Plug&Play (Easy Set-up) Yes Yes Yes Yes
RJ 12 / IR Pass Through Yes Yes Yes Yes
Power on Mode Yes Yes Yes Yes
USB Cloning Yes Yes Yes Yes
Logo Display with Time Out Setting (BMP/Movie) Yes Yes Yes Yes
Welcome Message Yes Yes Yes Yes
Music Mode (Input: PC/AV/Component/HDMI) Yes Yes Yes Yes
Music Mode BackLight on/off Yes Yes Yes Yes
Auto Source Mode Yes Yes Yes Yes
Energy Saving Mode (BLU control) Yes Yes Yes Yes
Clock Back Up Supply Yes Yes Yes Yes
Software Clock Yes Yes Yes Yes
Multi Code Remote Control Yes Yes Yes Yes
Screwed Remote Battery Cover Yes Yes Yes Yes
Smoovie Compatibility Yes Yes Yes Yes
Sound bar compatibility Yes Yes Yes Yes
Samsung LYNK™ DRM Yes Yes Yes Yes
Pro:Idiom Yes Yes Yes Yes
Input & Output
HDMI (Side/Rear) 2/2 2/2 2/2 2/2
USB (Side/Rear) 1/0 1/0 1/0 1/0
Component In (Y/Pb/Pr) (Side/Rear) 0/1 0/1 0/1 0/1
Composite In (AV) (Side/Rear) 0/1 (1 Common Use for Component Y) 0/1 (1 Common Use for Component Y) 0/1 (1 Common Use for Component Y) 0/1 (1 Common Use for Component Y)
Ethernet (LAN) (Side/Rear) 1/0 1/0 1/0 1/0
Digital Audio Out (Optical) (Side/Rear) 0/1 0/1 0/1 0/1
Audio Out (Mini Jack) (Side/Rear) 0/1 0/1 0/1 0/1
PC/DVI Audio In (Mini Jack) (Side/Rear) 0/1 0/1 0/1 0/1
RF In (Terrestrial/Cable input) (Side/Rear) 1/0 1/0 1/0 1/0
RS232C (Common Use for RJ12) (Common Use for RJ12) (Common Use for RJ12) (Common Use for RJ12)
Variable Audio Out (Side/Rear) 0/1 0/1 0/1 0/1
Variable Audio Out Volume Control (Side/Rear) 0/1 0/1 0/1 0/1
RJ12 for External Control (Side/Rear) 0/1 0/1 0/1 0/1
RJP Jack (Remote Jack Pack) (Side/Rear) 0/1 0/1 0/1 0/1
System
DTV Tuner ATSC / Clear QAM ATSC / Clear QAM ATSC / Clear QAM ATSC / Clear QAM
Analog Tuner Yes Yes Yes Yes
Design
Front Color Black Black Black Black
Stand Type U Stand U Stand U Stand U Stand
Dimension (WxHxD)
Set Dimension with Stand (WxHxD) (mm / Inch) 1033.3 x 639.20 x 208.8 / 40.68" x 25.17" x 8.22" 1224.8 x 747.5 x 267.7 / 48.22" x 29.43" x 10.54" 1447.3 x 886.1 x 316.9 / 56.98" x 34.89" x 12.48" 1670.2 x 1012.3 x 316.9 / 65.8" x 39.9" x 12.5"
Set Dimension without Stand (WxHxD) (mm / Inch) 1033.3 x 596.9 x 33.2 / 40.48" x 23.5" x 1.3" 1224.8 x 706.9 x 33.2 / 48.22" x 27.83" x 1.30" 1447.3 x 836.4 x 35.2 / 56.98" x 32.93" x 1.38" 1670.2 x 962.6 x 36.4 / 65.8" x 37.9" x 1.43"
Carton Dimensions
Package Dimension (WxHxD) (mm / Inch) 1110 x 668 x 140 / 43.7" x 26.3" x 1.72" 1340 x 800 x 152 / 52.75" x 31.49" x 5.98" 1571 x 945 x 182 / 61.85" x 37.20" x 7.17" 1810 x 300 x 1075 / 71.3" x 42.3" x 11.811"
Weight
Set Weight with Stand (kg / lbs) 12.5 / 27.6 lbs. 16.7 / 36.8 lbs. 26.1 / 57.5 lbs. 37.1 / 81.8 lbs.
Set Weight without Stand (kg / lbs) 11.3 / 24.9 lbs. 14.8 / 32.6 lbs. 22.7 / 50.0 lbs. 34 / 75 lbs.
Packaging Weight
Gross weight (kg / lbs) 15 / 33.1 lbs. 21.1 / 46.5 lbs. 32.4 / 71.4 lbs. 46.15 / 101.7 lbs.
VESA Mounting
Dimensions (mm) 400 x 400 400 x 400 400 x 400 400 x 400
Screw Size M8 M8 M8 M8
Power
Power Supply AC110-120V 60Hz AC110-120V 60Hz AC110-120V 60Hz AC110-120V 60Hz
Multi Voltage AC110-220V AC110-220V AC110-220V AC110-120V 60Hz
UPC
UPC 887276684420 887276684451 887276684468 8806086379038
Eco
Eco Mark TM1480 + TM1240 TM1480 + TM1240 TM1480 + TM1240 TM1480 + TM1240
Eco Sensor Yes Yes Yes Yes
Accessory
Package Dimension (WxHxD) (mm) Yes Yes Yes Yes
Battery (for Remote Control) Yes Yes Yes Yes
Vesa Wall Mount Support Yes Yes Yes Yes
Slim Gender Cable Yes Yes Yes Yes
Power Cable Yes Yes Yes Yes

Documentation:

Download the Samsung 890 Series Hospitality TVs Datasheet (.PDF)
